M22-2410642

Headers, Male Pins Overview

The M22-2410642 is a male pin header from the Harwin M22 series, designed for through-hole mounting. It features a right-angle configuration with a 2 mm pitch and accommodates 12 positions in a single row. The connector utilizes tin-plated phosphor bronze contacts housed in black nylon insulation. It supports a maximum voltage of 500 VAC and operates within a temperature range of -40°C to +105°C. This component is classified as headers and wire housings.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting for compact board integration
• Tin-plated contacts for reliable conductivity
• Nylon housing with UL 94 V-0 flammability rating

Headers, Male Pins Applications

• General electronic interconnections
• Industrial control systems
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

This component is officially discontinued and no longer manufactured by Harwin Inc. Procurement should focus on identifying verified replacement parts or alternative sources for existing inventory. Verify compatibility with current design requirements before sourcing substitutes. Do not rely on new production availability.

Headers, Male Pins Selection Notes

Select this part only if the specific right-angle, 12-position, 2 mm pitch form factor is required and existing stock is available. Due to its end-of-life status, engineers should evaluate equivalent active components that match the electrical ratings and mechanical dimensions to ensure long-term supply chain stability.

Headers, Male Pins Part Context

The M22 series represents a high-density connector system known for reliability in harsh environments. The M22-2410642 specifically addresses needs for angled connections where space constraints prevent straight headers. Its robust construction supports repeated mating cycles and vibration resistance typical in industrial applications.
