M22-2532046

Headers, Male Pins Overview

The Harwin M22-2532046 is a single-row pin header from the M22 series, designed for board-to-board connections. It features 20 positions with a 2.00 mm pitch and utilizes tin-plated contacts. The component is configured as a horizontal header, suitable for surface-mount applications where space efficiency is required. This specific part number represents a cuttable strip format, allowing for flexible assembly integration.

Headers, Male Pins Feature Summary

• Single row configuration with 20 positions
• 2.00 mm pitch spacing between contacts
• Tin-plated contact finish for reliable conductivity
• Horizontal orientation for low-profile mounting

Headers, Male Pins Applications

• Board-to-board interconnections in compact electronics
• Surface-mount assembly on PCBs
• Signal routing in consumer devices

Headers, Male Pins Procurement Notes

Verify the exact mechanical dimensions and termination style against the official datasheet before integration. Confirm that the tin plating specification meets the environmental requirements of the target application. Ensure compatibility with mating connectors within the same M22 series family to guarantee proper engagement and electrical continuity.

Headers, Male Pins Selection Notes

Select this component when a single-row, 20-position connection is needed with a 2.00 mm pitch. The horizontal design is optimal for applications requiring minimal height clearance. Verify that the tin finish aligns with solderability and corrosion resistance needs. Consider the cuttable nature of the strip if variable lengths are required during production.

Headers, Male Pins Part Context

This part belongs to the Harwin M22 series, which offers various configurations including right-angle and vertical headers. The M22 series is known for its compact size and reliability in high-density applications. The M22-2532046 specifically provides a horizontal variant, distinguishing it from other orientations in the product line while maintaining the standard 2.00 mm pitch.

Headers, Male Pins Replacement Considerations

Check for other M22 series parts with identical 20-position, 2.00 mm pitch specifications but different orientations or plating options. Ensure any substitute maintains the same single-row structure and horizontal mounting requirement for direct compatibility.
