M22-2540505

Headers, Male Pins Overview

The Harwin M22-2540505 is a male pin header from the M22 series, designed for board-to-board connections. It features a 2 mm pitch with 10 contacts arranged in a double row (5+5). The connector utilizes through-hole termination and is oriented at a right angle (horizontal) relative to the PCB. Constructed with phosphor bronze contacts plated with gold, it ensures reliable electrical performance. The housing is made of nylon, providing structural integrity for high-density applications.

Headers, Male Pins Feature Summary

• Right-angle horizontal configuration facilitates compact board stacking
• Gold-plated phosphor bronze contacts enhance conductivity and corrosion resistance
• Through-hole mounting offers secure mechanical attachment to the PCB

Headers, Male Pins Applications

• Board-to-board interconnects in industrial equipment
• High-density PCB assembly requiring space-efficient routing
• Electronic modules needing robust horizontal connection interfaces

Headers, Male Pins Procurement Notes

Verify the specific orientation suffix within the part number to confirm the right-angle horizontal design. Ensure that the target PCB footprint matches the 2 mm pitch and 5+5 contact arrangement. Confirm that the manufacturing source provides official datasheets to validate material specifications and compliance standards before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a horizontal board-to-board interface is required to save vertical space. The 2 mm pitch suits applications where moderate density is needed without extreme miniaturization. Verify that the mating connector supports the specified current ratings and that the through-hole process aligns with the assembly capabilities of the production line.

Headers, Male Pins Part Context

This component belongs to the Harwin M22 series, which focuses on high-reliability connectors for demanding environments. The series offers various configurations including straight and angled options. The M22-2540505 specifically addresses needs for horizontal connectivity, distinguishing it from standard vertical headers in the same family by altering the spatial orientation of the pins.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Harwin M22 series headers with identical 2 mm pitch and 10-contact double-row layouts. Ensure any replacement maintains the right-angle horizontal orientation and through-hole termination type. Cross-reference mating socket specifications to guarantee mechanical fit and electrical compatibility.
