M22-5330605

Headers, Male Pins Overview

The M22-5330605 is a surface mount header from the Harwin M22 series, featuring a single row of six positions with a 2.00mm (0.079 inch) pitch. Designed for right-angle board-to-board connections, it utilizes phosphor bronze contacts with gold plating to ensure reliable signal transmission. The component employs a solder termination method suitable for automated assembly processes. It operates within a temperature range of -40°C to +105°C and supports a rated voltage of 500V. The housing material provides structural integrity while maintaining a compact profile for high-density PCB layouts.

Headers, Male Pins Feature Summary

• Surface mount construction enables efficient automated placement on printed circuit boards
• Right-angle orientation facilitates compact vertical interconnections between stacked boards
• Gold-plated phosphor bronze contacts provide durable electrical conductivity and corrosion resistance

Headers, Male Pins Applications

• High-density electronic assemblies requiring vertical board stacking
• Industrial control systems with space-constrained internal architectures
• Consumer electronics utilizing multi-layer printed circuit board designs

Headers, Male Pins Procurement Notes

Verify that the specific order matches the surface mount right-angle configuration rather than through-hole variants within the M22 family. Confirm the six-position count and 2mm pitch align with the target PCB footprint. Ensure compatibility with standard reflow soldering profiles required for surface mount components. Cross-reference the manufacturer part number to distinguish from similar pin counts or orientations.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle interconnect solution is required for rigid board-to-board applications. The surface mount format eliminates the need for mechanical fasteners, reducing assembly complexity. Consider the 2mm pitch as a balance between signal density and manufacturing tolerance. Evaluate the thermal stability requirements against the specified operating temperature range before finalizing the design.

Headers, Male Pins Part Context

This connector belongs to the M22 series, which offers various configurations including through-hole and surface mount options in both straight and right-angle forms. The series is engineered for industrial standards, providing robust performance in demanding environments. The M22-5330605 specifically addresses needs for compact, vertically oriented connections where space efficiency and reliable solder joints are critical priorities.

Headers, Male Pins Replacement Considerations

Compatible mating connectors include female headers such as M22-6361042 or M22-6341042, which share the same 2mm pitch and contact interface specifications. Ensure that any substitute maintains the right-angle orientation and surface mount termination style to preserve the intended mechanical fit and electrical characteristics.
