M50-3202245

Headers, Receptacles, Female Sockets Overview

The Harwin M50-3202245 is a dual in-line (DIL) socket assembly belonging to the Archer M50 series. It features a 1.27 mm pitch and a 1.27 mm row spacing, designed for surface-mount technology (SMT) installation. The connector provides 44 positions arranged in two rows of 22 contacts each. Contacts are gold-plated phosphor bronze, ensuring reliable signal transmission. The housing is constructed from black polybutylene terephthalate (PBT), offering thermal stability up to 105°C and resistance down to -40°C. This component serves as a board-to-board interface with high-density capabilities.

Headers, Receptacles, Female Sockets Feature Summary

• Dual-row SMT receptacle design for compact board-to-board interconnects
• Gold-plated phosphor bronze contacts for enhanced conductivity and corrosion resistance
• Black PBT housing providing thermal stability across wide operating temperatures

Headers, Receptacles, Female Sockets Applications

• High-density electronic assemblies requiring surface-mount connectivity
• Industrial control systems utilizing board-to-board interfaces
• Telecommunications equipment with space-constrained layouts

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific datasheet revision when sourcing, as manufacturing updates may occur. Confirm that the supplier provides original Harwin Inc. documentation matching the M50-3202245 designation. Ensure compliance with RoHS directives if required by your project specifications. Cross-reference the pin count and orientation against your PCB footprint requirements before finalizing orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, dual-row surface-mount solution is required. The 1.27 mm pitch allows for higher density compared to standard connectors. Verify compatibility with mating pins or headers within the same M50 series family. Consider the 105°C temperature rating for applications involving significant thermal loads during operation.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Archer M50 series, known for its robust construction and reliability in demanding environments. The series offers various configurations including through-hole and IDC options. The M50-3202245 specifically addresses the need for dense, soldered connections without the complexity of wire harnesses, fitting into modern electronics manufacturing workflows.

Headers, Receptacles, Female Sockets Replacement Considerations

Consult official Harwin catalogs for direct substitutes within the M50 series. Verify mechanical dimensions and electrical ratings before adopting alternative manufacturers' components to ensure proper fit and function.
