M50-3500642

Headers, Male Pins Overview

The Harwin M50-3500642 is a 12-position, dual-row pin header from the Archer M50 series. It features a 1.27 mm pitch and right-angle through-hole solder termination. The connector utilizes gold-plated phosphor bronze contacts with a current rating of 1 A and voltage ratings up to 600 V. Designed for board-to-board or wire-to-board applications, it operates within a temperature range of -40°C to +105°C.

Headers, Male Pins Feature Summary

• Right-angle orientation facilitates compact PCB layout integration.
• Gold plating on phosphor bronze contacts ensures reliable signal transmission.
• Through-hole solder tail provides secure mechanical mounting.

Headers, Male Pins Applications

• Board-to-board interconnection systems
• Wire-to-board assembly configurations
• High-density electronic circuit boards

Headers, Male Pins Procurement Notes

Verify the specific part number against official Harwin documentation to confirm contact configuration and plating specifications. Ensure that the right-angle form factor aligns with the target PCB design requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle connection is required for high-density layouts. The 1.27 mm pitch allows for significant I/O density while maintaining standard electrical ratings suitable for general-purpose digital signals.

Headers, Male Pins Part Context

This component belongs to the Archer M50 series, which offers various position counts and orientations. The M50-3500642 specifically addresses needs for 12-position right-angle headers in space-constrained environments requiring robust through-hole mounting.

Headers, Male Pins Replacement Considerations

Consult official Harwin cross-reference guides for compatible alternatives. Verify that any substitute maintains the identical 1.27 mm pitch, right-angle geometry, and through-hole termination style to ensure mechanical fit.
