M50-3930342

Headers, Male Pins Overview

The Harwin M50-3930342 is a 3-position, dual-row pin header from the Archer M50 series. It features a 1.27 mm pitch and right-angle through-hole termination. The connector utilizes gold-plated brass contacts with a 1 A current rating. Operating temperatures range from -40°C to +105°C. The housing is constructed from black polyamide (PA) material.

Headers, Male Pins Feature Summary

• Right-angle configuration for compact board layout
• Gold-plated contacts ensure reliable signal transmission
• Through-hole soldering for secure PCB mounting

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• Industrial control systems
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix against official Harwin documentation to confirm contact plating thickness and housing material variations. Ensure compatibility with mating sockets regarding row spacing and pin length specifications before integration into final designs.

Headers, Male Pins Selection Notes

Select this component for applications requiring low-profile, right-angle connectivity with high reliability. The 1.27 mm pitch suits dense circuit layouts. Verify that the 1 A current rating meets system power requirements and that the operating temperature range aligns with environmental conditions.

Headers, Male Pins Part Context

This part belongs to the Archer M50 series, designed for high-density interconnects. The series offers various configurations including straight and angled headers. It supports both surface mount and through-hole technologies across multiple position counts.

Headers, Male Pins Replacement Considerations

Consult Harwin's official cross-reference guide for verified substitutes. Generic equivalents may not match the precise 1.27 mm pitch or gold plating specifications required for optimal performance.
