M50-4303245

Headers, Receptacles, Female Sockets Overview

The Harwin M50-4303245 is a board-to-board receptacle connector from the Archer M50 series. It features a dual-row configuration with 64 positions and a 1.27mm pitch. Designed for surface-mount technology (SMT), it utilizes gold-plated phosphor bronze contacts housed in black polyamide insulation. The component supports vertical mating and operates within a temperature range of -40°C to +105°C, ensuring reliable high-density interconnects.

Headers, Receptacles, Female Sockets Feature Summary

• Dual-row SMT receptacle design for compact board-to-board connections
• Gold-plated phosphor bronze contacts ensure stable signal transmission
• Black polyamide housing provides UL 94 V-0 flammability rating

Headers, Receptacles, Female Sockets Applications

• High-density electronic assemblies requiring robust board-to-board interconnects
• Industrial control systems utilizing surface-mount manufacturing processes
• Communication equipment demanding reliable signal integrity in confined spaces

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific part number against official Harwin documentation to confirm current production status and RoHS compliance details. Ensure that procurement channels provide authentic components with traceable origin. Cross-reference technical specifications with system requirements prior to ordering to prevent compatibility issues during assembly.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a 64-position dual-row SMT receptacle is required. Confirm that the mating header matches the 1.27mm pitch and vertical orientation. Validate that the PCB layout accommodates the specified height and footprint constraints associated with the Archer M50 series geometry.

Headers, Receptacles, Female Sockets Part Context

This connector belongs to the Archer M50 family, characterized by 1.27mm spacing and high reliability. It complements other M50 headers and sockets designed for dense electronic packaging. The series supports various row counts and mounting styles to facilitate flexible system integration across multiple hardware platforms.
