M50-4304545

Headers, Receptacles, Female Sockets Overview

The Harwin M50-4304545 is a surface-mount board-to-board receptacle from the Archer M50 series. It features a dual-row configuration with 10 positions and a 1.27 mm pitch. The connector utilizes gold-plated phosphor bronze contacts housed in black liquid crystal polymer (LCP). Designed for high-reliability applications, it supports a voltage rating of 1 kV and operates within a temperature range of -40°C to +105°C.

Headers, Receptacles, Female Sockets Feature Summary

• High-voltage capability up to 1 kV for robust signal integrity
• Gold-plated contacts ensure reliable electrical performance
• Surface-mount design facilitates automated assembly

Headers, Receptacles, Female Sockets Applications

• High-density electronic assemblies
• Industrial control systems
• Automotive electronics

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific part number against official Harwin documentation to confirm current availability and RoHS compliance status. Ensure that the selected component matches the required voltage and thermal specifications for the intended application environment before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a compact, high-voltage board-to-board connection is required. The 1.27 mm pitch allows for dense routing, while the LCP housing provides stability. Confirm that the SMT mounting style aligns with the manufacturing process and that the 10-position count meets the circuit interface requirements.

Headers, Receptacles, Female Sockets Part Context

This connector belongs to the Archer M50 family, known for precision interconnect solutions. The M50 series offers various configurations including headers and receptacles. This specific model serves as a female socket counterpart to male pin headers within the same ecosystem, ensuring mechanical and electrical compatibility across the product line.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes within the M50 series include M50-4300545 (5 positions) or M50-4301045 (10 positions), provided the pitch and row configuration remain consistent. Verify that any alternative maintains the 1 kV rating and SMT mounting characteristics.
