M50-4701845

Headers, Male Pins Overview

The M50-4701845 is a Harwin SMT header connector featuring a 2.00mm pitch and an 18-way configuration. It utilizes a dual-row arrangement with a 3.96mm overall height, designed for surface mount assembly on printed circuit boards. The component incorporates a gold-plated contact finish to ensure reliable signal transmission and corrosion resistance in electronic applications.

Headers, Male Pins Feature Summary

• Surface mount technology design for automated PCB assembly
• Dual-row configuration providing high density interconnection
• Gold-plated contacts ensuring durable electrical performance

Headers, Male Pins Applications

• Industrial control systems requiring robust connectivity
• Consumer electronics utilizing compact form factors
• Automotive embedded modules needing reliable signal paths

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Harwin documentation to confirm plating thickness and mating pin compatibility. Ensure the selected variant matches the required board thickness and soldering profile specifications for proper reflow soldering results.

Headers, Male Pins Selection Notes

Consider the mechanical retention requirements of the surface mount footprint when designing the PCB layout. Evaluate the mating connector interface to guarantee alignment and secure engagement without excessive insertion force or misalignment risks during assembly.

Headers, Male Pins Part Context

This component belongs to the Harwin M50 series, which focuses on space-saving interconnect solutions. The series offers various configurations tailored for modern electronics manufacturing trends emphasizing miniaturization and high reliability in dense circuit board environments.

Headers, Male Pins Replacement Considerations

Consult official cross-reference lists for compatible alternatives. Verify that any substitute maintains identical pitch, row count, and mounting style to ensure functional equivalence in existing designs.
