M50-4704045

Headers, Male Pins Overview

The M50-4704045 is a board connector from the Harwin Archer M50 series, featuring a 1.27 mm pitch and 40 positions arranged in two rows. It utilizes male contacts with gold plating for reliable signal transmission. The component is designed for straight surface mount installation with solder terminals. This shrouded connector supports polarization to prevent mis-mating during assembly.

Headers, Male Pins Feature Summary

• Shrouded housing design prevents misalignment
• Gold-plated male contacts ensure durability
• Polarization options available for secure mating

Headers, Male Pins Applications

• Board-to-board interconnections
• High-density electronic assemblies
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to confirm contact configuration and polarization requirements. Ensure compatibility with mating headers regarding height and row alignment. Confirm RoHS compliance status if required by project specifications before finalizing procurement.

Headers, Male Pins Selection Notes

Select this model for applications requiring high-density connections on a 1.27 mm grid. The shrouded design aids in automated placement and reduces insertion force risks. Verify that the target PCB layout accommodates the recommended pad pattern and that mating components match the male contact gender.

Headers, Male Pins Part Context

This component belongs to the Archer M50 family, known for compact board-to-board solutions. The series offers various pin counts and configurations optimized for space-constrained environments. The M50-4704045 specifically addresses needs for robust, polarized connections in dense layouts.

Headers, Male Pins Replacement Considerations

Direct substitutes within the same series include M50-4702045 (20 positions) or M50-4706045 (60 positions). Cross-series replacements require verifying pitch, current ratings, and mechanical dimensions to ensure functional equivalence.
