M50-4800645

Headers, Male Pins Overview

The Harwin M50-4800645 is a 12-position dual in-line (DIL) header connector from the ARCHER series. It features a 1.27 mm pitch and two rows of contacts with gold-plated copper alloy terminals. Designed for right-angle surface mount installation, it utilizes shrouded housings with PC tails for secure board attachment. The component supports a rated current of 1 A and a voltage rating of 300 V. Operating temperatures range from -40°C to +105°C.

Headers, Male Pins Feature Summary

• Shrouded housing design provides mechanical protection and alignment for mating sockets.
• Right-angle configuration facilitates compact vertical circuit board layouts.
• Gold plating on copper alloy contacts ensures reliable conductivity and corrosion resistance.

Headers, Male Pins Applications

• High-density electronic assemblies requiring robust board-to-board connections
• Industrial control systems operating within specified temperature ranges
• Consumer electronics utilizing surface mount technology for space-constrained designs

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Harwin documentation to confirm exact pin count, row configuration, and termination style. Ensure compatibility with mating socket heights ranging from 2.2 mm to 8.5 mm as defined by the ARCHER series specifications. Cross-reference RoHS compliance details directly with the manufacturer's latest release notes before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a right-angle, shrouded DIL header is required for high-density applications. The 1.27 mm pitch allows for tight spacing between circuits. Verify that the mating socket height falls within the supported range of 2.2 mm to 8.5 mm. Confirm that the surface mount PC tail termination method aligns with the assembly process capabilities and thermal profile requirements of the manufacturing line.

Headers, Male Pins Part Context

This part belongs to the Harwin ARCHER M50 series, which offers extensive variety in mating heights and styles. The series includes both single in-line (SIL) and dual in-line (DIL) configurations. The M50-4800645 specifically addresses needs for horizontal, right-angle connections with shrouded protection, distinguishing it from open-frame or straight-mount alternatives within the broader product family.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Direct replacement requires identical pitch, row count, and mounting orientation. Verify that any alternative component matches the 1.27 mm pitch and right-angle shrouded design to ensure mechanical and electrical compatibility without redesigning the PCB footprint.

Headers, Male Pins FAQ

What is the rated current and voltage for this connector?

The M50-4800645 has a rated current of 1 A and a voltage rating of 300 V.

Does this connector feature a shrouded housing?

Yes, the M50-4800645 is a shrouded header designed to protect contacts and guide mating connectors.

What is the contact material and plating?

The contacts are made of copper alloy with gold plating to ensure durability and low contact resistance.
