M50-4802745

Headers, Male Pins Overview

The Harwin M50-4802745 is a right-angle through-hole header connector from the Archer M50 series. It features a 1.27 mm pitch and a 54-position configuration arranged in a dual inline layout. The component utilizes gold-plated contacts for reliable signal transmission. Designed for board-to-board applications, it offers robust mechanical stability with shrouded housing to ensure proper alignment during mating.

Headers, Male Pins Feature Summary

• Right-angle orientation facilitates compact PCB layouts
• Gold-plated contacts ensure durable electrical performance
• Shrouded design provides precise pin alignment

Headers, Male Pins Applications

• Board-to-board interconnections
• Industrial control systems
• Aviation electronic equipment

Headers, Male Pins Procurement Notes

Verify the specific part number M50-4802745 against official Harwin documentation to confirm the 54-position count and right-angle termination type. Ensure compatibility with mating sockets within the Archer M50 series. Check for RoHS compliance status as indicated in current datasheets before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this connector when a high-density, right-angle interface is required for rigid board connections. The 1.27 mm pitch suits applications needing moderate spacing. Verify that the PCB footprint matches the dual inline shrouded header dimensions. Consider the through-hole mounting requirement and ensure sufficient board space for the vertical profile.

Headers, Male Pins Part Context

This component belongs to the Harwin Archer M50 series, known for high-reliability interconnects used in demanding environments. The series supports various configurations including straight and right-angle headers. The M50-4802745 specifically addresses needs for dense, angled connections in industrial and aerospace sectors where secure mating is critical.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Harwin M50 series right-angle headers with matching 1.27 mm pitch and dual inline configurations. Verify position count and shroud presence to ensure mechanical fit. Cross-reference with equivalent connectors from other manufacturers only if pinout and dimensional tolerances are identical.
