M50-4803845

Headers, Male Pins Overview

The M50-4803845 is a male pin header from the Harwin ARCHER M50 series, designed for through-hole mounting. It features a right-angle configuration with 76 positions arranged in a dual in-line layout. The connector utilizes a 1.27 mm (0.05 inch) pitch and includes gold-plated contacts for reliable signal transmission. Constructed with a black thermoplastic housing, it supports vertical board-to-board connections. The component is rated for operation between -40°C and +105°C, ensuring stability in demanding electronic environments.

Headers, Male Pins Feature Summary

• Right-angle through-hole design for compact vertical interconnects
• Gold-plated male pins ensure durable contact performance
• Dual in-line shrouded structure provides alignment and protection

Headers, Male Pins Applications

• Vertical board-to-board interconnections
• High-density electronic assemblies requiring right-angle routing
• Industrial control systems operating within specified temperature ranges

Headers, Male Pins Procurement Notes

Verify part authenticity through authorized Harwin distributors or certified suppliers. Confirm RoHS compliance status via official documentation before integration. Check current manufacturing status as this specific model may be obsolete; validate availability of active replacements if long-term supply continuity is required for production planning.

Headers, Male Pins Selection Notes

Select this component when right-angle through-hole mounting is necessary for high-pin-count applications. Ensure PCB footprint matches the 1.27 mm pitch and dual-row configuration. Consider thermal limits and mating force requirements against system specifications. Verify that the gold plating thickness meets environmental durability needs for the intended operational lifespan.

Headers, Male Pins Part Context

This part belongs to the ARCHER M50 series, known for high-reliability connectors in harsh environments. The series offers various configurations including surface mount and different row counts. The M50-4803845 specifically addresses needs for dense, right-angle connections using standard through-hole technology with robust mechanical locking features typical of the ARCHER line.

Headers, Male Pins Replacement Considerations

Public data indicates this part is obsolete. Similar substitutes include other Harwin M50 series headers with matching 1.27 mm pitch and 76-position count. Verify mechanical dimensions and electrical ratings before substitution. Consult Harwin official resources for current recommended alternatives.
