M50-4901645

Headers, Male Pins Overview

The Harwin M50-4901645 is a card edge connector from the ARCHER series, designed for high-density board-to-board applications. It features a 1.27 mm pitch and a dual-row configuration with 32 positions (16+16). The component utilizes gold-plated contacts to ensure reliable signal transmission in demanding environments. It supports surface mount technology for automated assembly processes.

Headers, Male Pins Feature Summary

• Dual-row architecture providing high I/O density within a compact footprint
• Gold contact plating ensures corrosion resistance and stable electrical performance
• Surface mount design facilitates efficient PCB integration

Headers, Male Pins Applications

• High-density data communication equipment
• Industrial control systems requiring robust interconnects
• Telecommunications infrastructure modules

Headers, Male Pins Procurement Notes

Verify current availability status as this component may be subject to discontinuation or limited supply. Confirm RoHS compliance details through official manufacturer documentation before finalizing procurement decisions. Ensure compatibility with existing manufacturing processes and quality standards.

Headers, Male Pins Selection Notes

Select this connector when high-density interconnection is required with a 1.27 mm pitch. Consider the dual-row layout for maximizing pin count per unit area. Evaluate surface mount requirements against available PCB space and thermal constraints during the design phase.

Headers, Male Pins Part Context

This part belongs to the ARCHER M50 series by Harwin Inc., known for precision engineering in electronic interconnects. The series offers various configurations tailored for different mounting styles and position counts, supporting diverse industrial and commercial electronics needs.

Headers, Male Pins Replacement Considerations

Check for direct substitutes within the same ARCHER M50 family that match the 1.27 mm pitch and dual-row specifications. Verify mechanical dimensions and electrical ratings to ensure functional equivalence without redesigning the host PCB.
