M52-5100445

Headers, Receptacles, Female Sockets Overview

The M52-5100445 is a vertical socket assembly from the Harwin ARCHER M52 series, designed for board-to-board connections. It features a 1.27 mm (0.05 in) pitch with 8 positions arranged in a single row. The connector utilizes solder pin termination and gold-plated female sockets to ensure reliable signal transmission. Constructed with a nylon housing, it supports through-hole mounting and operates within a temperature range of -40°C to +105°C. This component is part of the high-density ARCHER line, offering compact form factors for dense circuit layouts.

Headers, Receptacles, Female Sockets Feature Summary

• Vertical orientation for space-efficient PCB integration
• Gold-plated contacts for enhanced corrosion resistance
• Nylon housing material for thermal stability

Headers, Receptacles, Female Sockets Applications

• High-density electronic assemblies
• Board-to-board interconnect systems
• Compact consumer electronics modules

Headers, Receptacles, Female Sockets Procurement Notes

Verify current availability status as this specific part number may be discontinued or obsolete. Confirm compatibility with mating header specifications before procurement. Check for RoHS compliance documentation if required for your region. Ensure that the vertical height and pin configuration match your design requirements precisely.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, vertical socket with 8 positions is required. The 1.27 mm pitch suits applications needing moderate density without excessive board space usage. Consider the operating temperature range and voltage ratings against system demands. Verify that the single-row configuration aligns with the mating connector layout.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Harwin ARCHER M52 series, known for its high-density interconnect solutions. The series offers various configurations in terms of position count and row arrangements. The M52-5100445 specifically addresses needs for vertical, single-row socket connections with robust plating and standard through-hole mounting capabilities.

Headers, Receptacles, Female Sockets Replacement Considerations

Public sources indicate this part is obsolete. Potential substitutes include other ARCHER series sockets with identical 1.27 mm pitch, 8 positions, and vertical orientation. Verify mechanical dimensions and electrical ratings before substituting.
