M80-4031042

$14.75

Description：5+5 POS F DIL SHORT TAIL JKSCRW
Series：Datamate
Mfr：Harwin Inc.
Package：Tube

SKU:7532f74787db Category: Headers, Receptacles, Female Sockets Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M80-4031042 is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is 5+5 POS F DIL SHORT TAIL JKSCRW. Review the specifications below when checking this part for your BOM.

Headers, Receptacles, Female Sockets specifications for M80-4031042

Description：5+5 POS F DIL SHORT TAIL JKSCRW
Series：Datamate
Mfr：Harwin Inc.
Package：Tube
Connector Type：Header
Contact Type：Female Socket
Style：Board to Board or Cable
Number of Positions：10
Number of Positions Loaded：All
Pitch - Mating：0.079" (2.00mm)
Number of Rows：2
Row Spacing - Mating：0.079" (2.00mm)
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Threaded
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：-
Insulation Color：Black
Insulation Height：0.204" (5.17mm)
Contact Length - Post：0.079" (2.00mm)
Operating Temperature：-55°C ~ 125°C
Material Flammability Rating：UL94 V-0
Contact Finish - Post：Tin
Mated Stacking Heights：7.3mm, 7.55mm
Ingress Protection：-
Features：Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
Current Rating (Amps)：3.3A per Contact
Voltage Rating：-

Headers, Receptacles, Female Sockets datasheet and documents for M80-4031042

M80-4031042

Headers, Receptacles, Female Sockets Overview

The M80-4031042 is a Datamate J-Tek header connector manufactured by Harwin Inc. It features a 10-position configuration arranged in two rows of five, with a 2.00mm (0.079 inch) mating pitch. Designed for vertical through-hole mounting, this male pin connector utilizes gold-plated contacts on beryllium copper and a black polyphenylene sulfide (PPS) housing reinforced with glass fiber. The component operates within a temperature range of -55°C to +125°C and carries UL94 V-0 flammability ratings.

Headers, Receptacles, Female Sockets Feature Summary

High-reliability four-finger beryllium copper contacts ensure connection integrity under vibration and shock
Polyphenylene sulfide insulation provides robust thermal stability and chemical resistance
Integrated locking hardware secures mating pairs against accidental disengagement

Headers, Receptacles, Female Sockets Applications

Automotive electronic systems requiring high durability
Military equipment operating in harsh environments
General industrial control boards

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix code to confirm the inclusion of the required 101 locking hardware set. Confirm that the current manufacturing batch aligns with the latest material change notices issued by Harwin. Ensure compatibility with corresponding female receptacles from the same Datamate J-Tek series before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this model when a vertical male header is required for board-to-board connections. The 2.00mm pitch suits dense layouts, while the through-hole termination offers mechanical strength. Consider the integrated locking mechanism if the application involves significant mechanical stress or vibration during operation.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Datamate J-Tek series, designed for safety-critical applications. The series emphasizes high cycle life and performance in extreme conditions. The M80-4031042 specifically addresses needs for reliable vertical interconnects with secure locking capabilities in compact form factors.
