MAL211914152E3

MAL211914152E3 is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Vishay Beyschlag/Draloric/BC Components. Its product description is CAP ALUM 1500UF 10V AXIAL TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for MAL211914152E3

• Description：CAP ALUM 1500UF 10V AXIAL TH
• Series：119 AHT-DIN
• Mfr：Vishay Beyschlag/Draloric/BC Components
• Package：Tape & Reel (TR)
• Capacitance：1500 µF
• Tolerance：-10%, +50%
• Voltage - Rated：10 V
• ESR (Equivalent Series Resistance)：230mOhm @ 100Hz
• Lifetime @ Temp.：8000 Hrs @ 125°C
• Operating Temperature：-55°C ~ 125°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：1.1 A @ 100 Hz
• Ripple Current @ High Frequency：-
• Lead Spacing：-
• Size / Dimension：0.709" Dia x 1.181" L (18.00mm x 30.00mm)
• Height - Seated (Max)：-
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Axial, Can
• Impedance：170 mOhms

Aluminum Electrolytic Capacitors datasheet and documents for MAL211914152E3
