MFM-15-3.3

MFM-15-3.3 is listed in the AC DC Converters range at ChipApex. The manufacturer field lists MEAN WELL USA Inc.. Its product description is AC/DC CONVERTER 3.3V 12W. Review the specifications below when checking this part for your BOM.

AC DC Converters specifications for MFM-15-3.3

• Description：AC/DC CONVERTER 3.3V 12W
• Series：MFM-15 (15W)
• Mfr：MEAN WELL USA Inc.
• Package：Box
• Type：Open Frame
• Number of Outputs：1
• Voltage - Input：80 ~ 264 VAC
• Voltage - Output 1：3.3V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：3.5A
• Applications：Household Appliances, Medical
• Features：Universal Input
• Operating Temperature：-35°C ~ 85°C (With Derating)
• Efficiency：83.50%
• Mounting Type：Through Hole
• Package / Case：4-DIP Module
• Size / Dimension：1.93" L x 0.94" W x 0.91" H (49.0mm x 23.8mm x 23.0mm)
• Approval Agency：CB, CE, cURus, EAC, TUV
• Standard Number：-
• Power (Watts)：12 W

AC DC Converters datasheet and documents for MFM-15-3.3
