MGJ2D052005SC

MGJ2D052005SC is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Murata Power Solutions Inc.. Its product description is DC DC CONVERTER 20V -5V 2W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for MGJ2D052005SC

• Description：DC DC CONVERTER 20V -5V 2W
• Series：MGJ2 (2W)
• Mfr：Murata Power Solutions Inc.
• Package：Tube
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：4.5V
• Voltage - Input (Max)：5.5V
• Voltage - Output 1：20V
• Voltage - Output 2：-5V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：80mA, 40mA
• Power (Watts)：2 W
• Voltage - Isolation：5.2 kV
• Applications：ITE (Commercial), Medical
• Features：SCP
• Operating Temperature：-40°C ~ 95°C
• Efficiency：78.50%
• Mounting Type：Through Hole
• Package / Case：7-SIP Module, 5 Leads
• Size / Dimension：0.77" L x 0.39" W x 0.50" H (19.7mm x 10.0mm x 12.7mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for MGJ2D052005SC
