MPX2202D

Pressure Sensors Transducers Overview

The MPX2202D is a differential pressure sensor manufactured by NXP USA Inc., designed for board mount applications. It features a working pressure of 29.01 PSI (200 kPa) and a maximum pressure of 58.02 PSI (400 kPa). The device provides an output signal ranging from 0 mV to 40 mV at 10 V excitation via a Wheatstone bridge configuration. It operates within a temperature range of -40°C to 125°C and utilizes a 4-SIP module package with through-hole mounting.

Pressure Sensors Transducers Feature Summary

• Temperature compensated for enhanced accuracy across operating ranges
• Integrated Wheatstone bridge output for direct signal processing
• Designed for surface or board mount integration

Pressure Sensors Transducers Applications

• Board mount pressure measurement systems
• Differential pressure monitoring in industrial environments
• Applications requiring temperature compensated sensing

Pressure Sensors Transducers Procurement Notes

Verify component status as the MPX2202D is listed as obsolete by the manufacturer. Confirm availability through authorized distributors or secondary market suppliers. Ensure compatibility with existing board layouts and through-hole assembly processes. Check for RoHS compliance documentation if required for specific regulatory standards. Validate that the 4-SIP package dimensions match the design constraints.

Pressure Sensors Transducers Selection Notes

Select this component for applications requiring differential pressure sensing up to 200 kPa. Consider the 4-SIP package for through-hole mounting requirements. Evaluate the need for temperature compensation in varying thermal environments. Assess the 0-40 mV output range against available signal conditioning circuitry. Verify that the operating temperature range meets environmental specifications.

Pressure Sensors Transducers Part Context

The MPX2202D belongs to the MPX2202 series of pressure sensors, which are piezoresistive devices. This series includes both absolute and differential variants. The MPX2202D specifically addresses differential pressure needs. It shares common characteristics with other members of the family, such as temperature compensation and similar output ranges, but differs in port configuration and pressure type.

Pressure Sensors Transducers Replacement Considerations

Public confirmed substitute part numbers: MPXM2202A, MPXV2202DPT1.
