MPX2300DT1

Pressure Sensors Transducers Overview

The MPX2300DT1 is a differential board-mount pressure sensor manufactured by NXP Semiconductors. It features an integrated temperature-compensated silicon chip housed in a SIP-4 package. The device operates with a supply voltage range of 1 V to 10 V and draws a typical supply current of 1 mA. It provides an analog output signal corresponding to the applied differential pressure. The sensor is designed for a maximum operating pressure of 5.8 psi (approximately 40 kPa) and maintains an accuracy of 1.5%. It functions within a temperature range of +15°C to +40°C.

Pressure Sensors Transducers Feature Summary

• Integrates temperature compensation and calibration on a single silicon chip
• Provides analog output signal proportional to differential pressure
• Housed in a compact SIP-4 surface mount package

Pressure Sensors Transducers Applications

• HVAC system pressure monitoring
• Medical device gas flow sensing
• Industrial process control instrumentation

Pressure Sensors Transducers Procurement Notes

Verify that the component source is an authorized NXP distributor to ensure authenticity, as counterfeit sensors may exhibit inaccurate pressure readings or failure to meet specified electrical parameters. Confirm the specific tape-and-reel packaging configuration matches your automated assembly requirements. Check for any recent product change notices regarding pinout or material composition updates before finalizing procurement orders.

Pressure Sensors Transducers Selection Notes

Select this component when a low-cost, analog-output solution is required for moderate differential pressure ranges up to 5.8 psi. Ensure the application environment stays within the specified +15°C to +40°C operational temperature limits. Consider the SIP-4 package dimensions for PCB layout constraints. This part is suitable for applications where high precision is not critical but cost-effectiveness and integration are priorities.

Pressure Sensors Transducers Part Context

The MPX2300DT1 belongs to the MPX230x series of pressure sensors from NXP. These devices utilize a piezoresistive silicon technology to measure differential pressure. The series is characterized by its small form factor and integrated signal conditioning, making it distinct from discrete pressure transducers that require external amplification circuits.

Pressure Sensors Transducers Replacement Considerations

Consult official NXP documentation for direct cross-reference parts. Verify compatibility of pin assignments and mechanical footprint if substituting with other SIP-4 pressure sensors. Ensure replacement components support the same 1.5% accuracy and 5.8 psi maximum pressure rating.
