NSR020A0X543Z

NSR020A0X543Z is listed in the DC DC Converters range at ChipApex. The manufacturer field lists OmniOn Power™. Its product description is DC DC CONVERTER 0.59-6V 120W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for NSR020A0X543Z

• Description：DC DC CONVERTER 0.59-6V 120W
• Series：Naos Raptor
• Mfr：OmniOn Power™
• Package：Tray
• Type：Non-Isolated PoL Module
• Number of Outputs：1
• Voltage - Input (Min)：4.5V
• Voltage - Input (Max)：14.4V
• Voltage - Output 1：0.59 ~ 6V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：20A
• Power (Watts)：120 W
• Voltage - Isolation：-
• Applications：ITE (Commercial)
• Features：Remote On/Off, OCP, OTP, UVLO
• Operating Temperature：-40°C ~ 85°C
• Efficiency：95%
• Mounting Type：Through Hole
• Package / Case：10-SIP Module
• Size / Dimension：1.45" L x 0.36" W x 0.61" H (36.8mm x 9.2mm x 15.5mm)
• Supplier Device Package：-
• Control Features：Enable, Active High
• Approval Agency：-
• Standard Number：-

DC DC Converters datasheet and documents for NSR020A0X543Z
