PBC25DBAN

Headers, Male Pins Overview

The PBC25DBAN is a male header connector manufactured by Sullins Connector Solutions, designed for board-to-board or cable applications. It features a dual-row configuration with 50 positions and a 0.100-inch (2.54mm) pitch. The connector utilizes right-angle through-hole termination with solder end connections. Contacts are made of phosphor bronze, featuring gold plating on the mating interface and tin plating on the tail. The housing is constructed from black polybutylene terephthalate (PBT), rated UL94 V-0, and operates within a temperature range of -65°C to 125°C.

Headers, Male Pins Feature Summary

• Dual-row unshrouded header design with push-pull locking mechanism
• Gold-plated mating contacts for reliable signal transmission
• Right-angle through-hole mounting for space-efficient PCB integration
• High-temperature resistant PBT insulation material

Headers, Male Pins Applications

• Industrial control system interconnections
• Consumer electronics board assembly
• Telecommunications equipment headers
• Automotive electronic module connections

Headers, Male Pins Procurement Notes

Verify that the specific part number PBC25DBAN matches the required 50-position count and right-angle orientation before procurement. Confirm that the supplier provides original manufacturer documentation to ensure compliance with the specified gold and tin plating thicknesses. Ensure storage conditions maintain the integrity of the phosphor bronze contacts and PBT housing properties.

Headers, Male Pins Selection Notes

Select this component when a dual-row, right-angle male header is required for high-density PCB layouts. The 0.100-inch pitch accommodates standard wire harnesses and mating connectors. Consider the push-pull locking feature if vibration resistance is necessary. Verify that the 3A current rating and 125°C operating temperature meet the thermal and electrical demands of the target application environment.

Headers, Male Pins Part Context

This component belongs to the PBC series of rectangular connectors from Sullins Connector Solutions. The series offers various position counts and orientations, including straight and right-angle configurations. The PBC25DBAN specifically represents the 50-position variant in the dual-row right-angle format, sharing common housing materials and contact specifications with other members of the family.
