PE7017-1

Attenuators Overview

The PE7017-1 is a fixed attenuator manufactured by Pasternack, designed for RF applications up to 18 GHz. It provides a precise attenuation value of 1 dB with an impedance of 50 Ohms. The component features N-type connectors, specifically N Male to N Female configuration. It is rated for a power handling capacity of 25 Watts within the specified frequency range. This device ensures signal level control in high-frequency circuits while maintaining low insertion loss characteristics typical of precision fixed attenuators.

Attenuators Feature Summary

• Provides precise 1 dB attenuation for signal level adjustment
• Operates effectively across a wide frequency range up to 18 GHz
• Features robust N Male to N Female connector interface
• Supports high power handling capabilities of 25 Watts

Attenuators Applications

• RF test and measurement equipment calibration
• Signal conditioning in microwave communication systems
• Attenuation stages in radar system architectures
• Laboratory setups requiring precise signal reduction

Attenuators Procurement Notes

Verify the specific part number suffix against official Pasternack documentation to confirm connector gender and attenuation value. Ensure that the required power rating of 25 Watts aligns with your system's thermal management capabilities. Confirm impedance matching requirements for your 50 Ohm environment before procurement to prevent signal reflection issues.

Attenuators Selection Notes

Select this model when a fixed 1 dB reduction is required at frequencies extending to 18 GHz. Consider the N-type interface compatibility with existing cabling infrastructure. Evaluate the 25 Watt power rating against peak signal levels to ensure reliable operation without thermal degradation or performance drift during continuous use.

Attenuators Part Context

This component belongs to the category of N-type fixed attenuators produced by Pasternack. These devices are engineered for consistent performance in demanding RF environments. The series typically includes various attenuation values and power ratings, serving as essential passive components for signal integrity management in high-frequency electronic systems.

Attenuators Replacement Considerations

Direct substitutes may include other manufacturers' N-type 1 dB fixed attenuators rated for 18 GHz and 25 Watts. Verify mechanical dimensions and connector tolerances to ensure physical compatibility. Check VSWR specifications to maintain equivalent signal transmission quality.
