PE7018-10

Attenuators Overview

The Pasternack PE7018-10 is a fixed attenuator designed for RF applications, featuring SMA male to female connectors. It provides a nominal attenuation of 10 dB with a power rating of 25 Watts and operates up to 18 GHz. The unit maintains a VSWR of 1.3:1 maximum and an attenuation accuracy of ±0.4 dB. Constructed with gold-plated brass connectors and a nickel-plated brass body, it ensures durability and reliable signal performance in high-power environments.

Attenuators Feature Summary

• Provides precise 10 dB signal reduction for RF systems
• Supports high power handling up to 25 Watts
• Operates across a wide frequency range up to 18 GHz
• Features durable SMA male-to-female interface

Attenuators Applications

• RF test and measurement setups
• Signal level adjustment in communication systems
• High-power microwave circuit integration

Attenuators Procurement Notes

Verify the specific connector gender configuration (SMA Male to Female) matches your system requirements. Confirm that the 25 Watt power rating and 18 GHz frequency limit are sufficient for your operational environment. Ensure compatibility with standard SMA mating interfaces to maintain signal integrity and prevent mechanical damage during installation.

Attenuators Selection Notes

Select this model when a fixed 10 dB attenuation is required at high power levels. It is suitable for applications needing stable performance up to 18 GHz. Consider the physical size and weight constraints if space is limited. Compare with variable attenuators if adjustable attenuation is needed instead of a fixed value.

Attenuators Part Context

This component belongs to Pasternack's line of fixed attenuators, which offer precise signal control without active components. The series includes various attenuation values and power ratings to suit different RF needs. Fixed attenuators like this model provide consistent performance and reliability, making them essential for maintaining signal levels in complex RF chains.

Attenuators Replacement Considerations

Check for compatible fixed attenuators from other manufacturers offering similar 10 dB attenuation, 25W power rating, and SMA connections. Verify that substitute parts meet or exceed the 18 GHz frequency range and VSWR specifications. Ensure mechanical dimensions and connector tolerances are compatible with existing mounting hardware.
