PEANLP1014

$187.40

Description：698-6000 MHz, 10 to 11 dBi gain,
Series：-
Mfr：Pasternack
Package：Retail Package

SKU:25ed9a7a64f9 Category: RF Antennas Brand: Pasternack

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PEANLP1014 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Pasternack. Its product description is 698-6000 MHz, 10 to 11 dBi gain,. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for PEANLP1014

Description：698-6000 MHz, 10 to 11 dBi gain,
Series：-
Mfr：Pasternack
Package：Retail Package
RF Family/Standard：Cellular, WiFi
Frequency Group：Wide Band
Frequency (Center/Band)：3.349GHz
Frequency Range：698MHz ~ 6GHz
Antenna Type：Panel
Number of Bands：1
VSWR：1.7
Return Loss：-
Gain：11dBi
Features：Cable - 200mm
Termination：N Type Female
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Bracket Mount
Height (Max)：17.500" (444.50mm)
Applications：4G, 5G, 802.11a/b/g/n/ac/ad/ah/ax, GSM, IoT, LoRa, LPWAN, LTE-M, M2M, NB-IoT, Wi-Fi, WLAN
Power - Max：100 W

Antennas RF datasheet and documents for PEANLP1014

PEANLP1014

Antennas RF Overview

The PEANLP1014 is a directional log periodic antenna manufactured by Pasternack, designed for multi-band operation within the 698 MHz to 960 MHz frequency range. It provides a nominal gain of 10-11 dBi across its operational spectrum. The component features a Type N female connector interface and is constructed as a low PIM series device to minimize passive intermodulation distortion. This antenna is engineered for reliable signal transmission in communication systems requiring broad bandwidth coverage.

Antennas RF Feature Summary

Directional radiation pattern optimized for targeted signal coverage
Multi-band capability supporting frequencies from 698 MHz to 960 MHz
Low Passive Intermodulation (PIM) design for signal integrity
Nominal gain ranging between 10 and 11 dBi

Antennas RF Applications

5G network infrastructure deployment
LTE cellular base station upgrades
CDMA communication system expansion
IoT connectivity enhancement
Wi-Fi signal boosting applications

Antennas RF Procurement Notes

Verify the specific datasheet version and technical specifications directly with Pasternack or authorized distributors before procurement. Confirm that the Type N female connector compatibility matches existing system requirements. Ensure the low PIM characteristics meet the specific interference thresholds required for the intended installation environment. Check for any regional supply restrictions or availability updates prior to ordering.

Antennas RF Selection Notes

Select the PEANLP1014 when a directional solution is required for the 698-960 MHz band. Its low PIM rating makes it suitable for dense urban deployments where intermodulation interference must be minimized. The included mounting bracket facilitates installation on standard poles or structures. Consider this model over omnidirectional alternatives when focused coverage and higher gain are necessary for extending range in specific directions.

Antennas RF Part Context

This component belongs to Pasternack's portfolio of RF antennas designed for modern wireless communication standards. It complements other directional and omnidirectional solutions offered by the manufacturer. The PEANLP1014 specifically addresses the need for high-gain, low-interference antennas in multi-band environments, supporting various wireless technologies including LTE and 5G.

Antennas RF Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult Pasternack engineering for direct replacements if this model is discontinued or unavailable.
