PEC05SBDN

Headers, Male Pins Overview

The PEC05SBDN is a male card edge connector manufactured by Sullins Connector Solutions. It features a 5-position single-row configuration with a 0.100-inch (2.54mm) spacing. Designed for right-angle through-hole mounting, the connector utilizes phosphor bronze contacts with tin plating to ensure reliable signal transmission. The housing is constructed from black polybutylene terephthalate (PBT), rated UL94 V-0 for flammability. It operates within a temperature range of -65°C to 125°C and supports a maximum current rating of 3A per contact.

Headers, Male Pins Feature Summary

• Right-angle board-to-board or cable interconnection capability
• Through-hole termination for secure PCB mounting
• Tin-plated phosphor bronze contacts for conductivity
• UL94 V-0 rated PBT insulation material

Headers, Male Pins Applications

• Industrial control system circuit boards
• Consumer electronics internal connections
• Telecommunications equipment interfaces
• General-purpose computing hardware modules

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to confirm pin count, orientation, and plating specifications. Ensure compatibility with target PCB hole sizes and mating card edge thicknesses. Confirm RoHS compliance status and moisture sensitivity level requirements for the intended assembly process before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle male header is required for single-row card edge applications. The 0.100-inch pitch suits standard density layouts. Consider the tin plating for general use rather than high-corrosion environments requiring gold. Validate that the 3A current rating meets the electrical load requirements of the specific circuit design.

Headers, Male Pins Part Context

This part belongs to the PEC05 series of rectangular connectors from Sullins Connector Solutions. The series offers various configurations including breakaway headers and different row counts. The PEC05SBDN specifically addresses the need for right-angle, single-row male connections in compact electronic assemblies.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Sullins PEC05 series variants such as PEC05DACN for vertical orientations. Cross-manufacturer replacements require matching the 0.100-inch pitch, 5-position count, right-angle form factor, and through-hole termination style.
