PI3DPX1235Q2ZLBEX

Signal Buffers, Repeaters, Splitters Overview

The PI3DPX1235Q2ZLBEX is a DisplayPort (DP) 2.1 UHBR13.5 and USB 3.2 Gen 2 linear ReDriver signal conditioner manufactured by Diodes Incorporated. It integrates a 6:4 active multiplexer to support data rates up to 13.5 Gbps, compliant with VESA DP Alt 2.1 UHBR13.5 and USB 3.2 Gen 2 standards. The device accommodates various channel configurations including single-channel USB 3.2, dual-channel USB 3.2 and DP 2.1 UHBR13.5, or four-channel DP 2.1 UHBR13.5, all multiplexed to a USB Type-C interface. It operates at a maximum supply voltage of 3.3 V, supports an I2C clock frequency of 1 MHz, and functions within a temperature range of -40°C to +105°C. The component is housed in a W-QFN-40 package.

Signal Buffers, Repeaters, Splitters Feature Summary

• Integrates a 6:4 active multiplexer for flexible lane allocation across USB and DisplayPort signals.
• Provides linear signal conditioning to correct equalization, output swing linearity, and flat gain values via I2C control.
• Supports high-speed data transmission up to 13.5 Gbps for next-generation display and connectivity interfaces.

Signal Buffers, Repeaters, Splitters Applications

• USB Type-C automotive product applications
• DisplayPort 2.1 UHBR13.5 interface implementations
• USB 3.2 Gen 2 signal integrity enhancement

Signal Buffers, Repeaters, Splitters Procurement Notes

Verify the specific suffix '2ZLBEX' against official Diodes Incorporated documentation to confirm packaging and tape-and-reel specifications. Ensure compatibility with the W-QFN-40 footprint and validate that the -40°C to +105°C operating temperature range meets the target environmental requirements. Cross-reference the I2C control interface requirements with the system controller capabilities before integration.

Signal Buffers, Repeaters, Splitters Selection Notes

Select this component when designing systems requiring simultaneous support for DisplayPort 2.1 UHBR13.5 and USB 3.2 Gen 2 protocols over a single USB Type-C connector. The integrated 6:4 mux reduces external component count compared to discrete solutions. Confirm that the PCB layout supports the W-QFN-40 package dimensions and thermal dissipation needs for the specified 3.3 V operation.

Signal Buffers, Repeaters, Splitters Part Context

This part belongs to the PI3DPX1235Q family of active display signal conditioners designed for high-bandwidth multimedia interfaces. It serves as a bridge between host controllers and downstream displays or peripherals, ensuring signal integrity over long traces or complex routing paths typical in modern mobile and automotive electronics.

Signal Buffers, Repeaters, Splitters Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Consult Diodes Incorporated for current alternative recommendations based on specific pin-to-pin or functional requirements.
