PK-16N04WA-01Q

$10.00

Description：BUZZER MAGN 1.5V 31X17MM FLANGE
Series：PK
Mfr：Mallory Sonalert Products Inc.
Package：Bulk

SKU:0d5c0a2b2314 Category: Alarms, Buzzers, and Sirens Brand: Mallory Sonalert Products Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PK-16N04WA-01Q is listed in the Alarms, Buzzers, And Sirens range at ChipApex. The manufacturer field lists Mallory Sonalert Products Inc.. Its product description is BUZZER MAGN 1.5V 31X17MM FLANGE. Review the specifications below when checking this part for your BOM.

Alarms, Buzzers, And Sirens specifications for PK-16N04WA-01Q

Description：BUZZER MAGN 1.5V 31X17MM FLANGE
Series：PK
Mfr：Mallory Sonalert Products Inc.
Package：Bulk
Driver Circuitry：Indicator, Internally Driven
Input Type：DC
Frequency：400Hz
Technology：Magnetic
Operating Mode：Single Tone
Duration：-
Sound Pressure Level (SPL)：75dB @ 1.5V, 30cm
Current - Supply：30mA
Port Location：Top
Operating Temperature：-20°C ~ 70°C
Approval Agency：-
Ratings：-
Ingress Protection：-
Mounting Type：Panel Mount, Flange
Termination：Wire Leads
Height - Seated (Max)：0.602" (15.30mm)
Voltage - Rated：1.5 V
Voltage Range：1.5 ~ 2V
Size / Dimension：1.220" L x 0.669" W (31.00mm x 17.00mm)

Alarms, Buzzers, And Sirens datasheet and documents for PK-16N04WA-01Q

PK-16N04WA-01Q

Alarms, Buzzers, And Sirens Overview

The PK-16N04WA-01Q is an electromechanical audio indicator manufactured by Mallory Sonalert Products Inc. It operates on a constant tone at a frequency of 400 Hz with a sound pressure level of 75 dBA measured at 30 cm when driven by 1.5 VDC. The device draws a current of 30 mA and features wire lead termination for connection. Physically, it measures 24 mm in length, 17 mm in width, and 15 mm in height, designed for flange mount installation.

Alarms, Buzzers, And Sirens Feature Summary

Internally driven electromechanical design for direct signal input
Continuous tone output optimized for clear auditory alerts
Compact form factor suitable for tight panel spaces

Alarms, Buzzers, And Sirens Applications

Industrial control panels requiring low voltage status indication
Medical equipment signaling systems
Transportation vehicle instrumentation

Alarms, Buzzers, And Sirens Procurement Notes

Verify the specific voltage rating against application requirements, as this model is specified for 1.5 VDC operation. Confirm that the flange mount style and wire lead termination are compatible with the intended enclosure design. Ensure the 75 dBA acoustic output meets the necessary audibility standards for the deployment environment. Cross-reference the physical dimensions to guarantee proper fit within the designated mounting aperture.

Alarms, Buzzers, And Sirens Selection Notes

Select this component when a low-voltage, internally driven audible alert is required. The 1.5 VDC specification limits its use to battery-powered or low-voltage logic circuits. Consider the 75 dBA output level relative to ambient noise conditions. The flange mount option provides secure attachment without additional hardware, simplifying assembly compared to screw-mount alternatives.

Alarms, Buzzers, And Sirens Part Context

This part belongs to the PK series of industrial buzzers from Mallory Sonalert. The series is characterized by robust construction and reliable performance in demanding environments. These indicators are widely recognized for their consistency in producing clear warning tones across various industrial and commercial applications.
