PXEUGLJAYF-25.000000

Oscillators Overview

The PXEUGLJAYF-25.000000 is a surface-mount crystal oscillator manufactured by Taitien, designed for precise clock generation in electronic systems. It operates at a nominal frequency of 25 MHz with a standard supply voltage of 3.3 V, ranging from 3.135 V to 3.465 V. The component utilizes a 6-pad ceramic SMD package measuring 7.5 mm x 5.0 mm x 1.9 mm. It features low phase jitter, typically max 0.5 pSec, and supports output frequencies up to 320 MHz. The device offers complementary outputs and includes enable/disable functionality.

Oscillators Feature Summary

• Complementary output configuration for flexible signal interfacing
• Low phase jitter performance ensuring stable timing signals
• Enable/Disable function for power management control
• Tight symmetry available for improved signal integrity

Oscillators Applications

• Communications equipment requiring stable clock sources
• Networking infrastructure components
• Industrial automation systems
• Automotive electronics applications

Oscillators Procurement Notes

Verify the specific part number against official Taitien documentation to confirm current availability and manufacturing status. Note that Taitien has issued product change notices regarding older PX and PY series parts, potentially replacing them with newer designations such as the PXEUG series. Ensure compatibility with existing board layouts and electrical specifications before procurement.

Oscillators Selection Notes

Select this oscillator when a 25 MHz CMOS output is required in a compact 7.5x5.0mm package. Consider its low jitter characteristics for sensitive timing applications. Verify that the 3.3V supply range aligns with system power rails. Check if complementary outputs are necessary for the specific circuit design requirements.

Oscillators Part Context

This component belongs to Taitien's line of quartz frequency control products, which include crystals, oscillators, and resonators. Taitien is a global manufacturer established in 1976, known for producing precision timing solutions for various industries including telecommunications and consumer electronics. The PXEUG series represents an evolution in their surface-mount oscillator portfolio.

Oscillators Replacement Considerations

Check for direct substitutes within the Taitien PXEUG family or equivalent offerings from other manufacturers. Be aware of potential obsolescence notices for related PX/PY series parts. Ensure any replacement matches the 25 MHz frequency, 3.3V operation, and 6-pin package dimensions.
