R5F562TAAGFF#V3

Microcontrollers Overview

The R5F562TAAGFF#V3 is a 32-bit microcontroller from the Renesas RX62T series, utilizing the RX core architecture. It features 128 kB of program memory and 8 kB of data RAM within an LQFP-80 surface-mount package. The device supports a maximum clock frequency of 100 MHz and includes 44 I/O pins. It operates on a power supply voltage ranging from 4 V to 5.5 V.

Microcontrollers Feature Summary

• Integrates high-performance RX CPU core for efficient code execution
• Provides flexible connectivity through multiple communication interfaces
• Includes integrated analog-to-digital conversion capabilities

Microcontrollers Applications

• Industrial control systems
• Automotive instrumentation
• Consumer electronics devices

Microcontrollers Procurement Notes

Verify component authenticity by checking manufacturer markings against official datasheets. Confirm package integrity and pin alignment prior to assembly. Ensure storage conditions comply with humidity sensitivity levels specified in the manufacturing documentation to prevent damage during handling.

Microcontrollers Selection Notes

Select this model when a balance of moderate memory capacity and compact packaging is required. The 80-pin form factor suits designs with limited board space but sufficient I/O needs. Consider the specific voltage range and peripheral requirements relative to alternative RX62T variants.

Microcontrollers Part Context

This component belongs to the RX62T family, which shares architectural compatibility with other members of the RX group. The series offers code upward compatibility, facilitating software reuse across different product lines. It targets applications requiring robust processing power within a standardized footprint.

Microcontrollers Replacement Considerations

Consult official substitution lists for verified equivalents. Cross-reference pinouts and electrical specifications carefully before integrating any alternative components into existing designs.
