RTCN-5006

Power Line Filter Modules Overview

The RTCN-5006 is a single-phase power line filter manufactured by TDK-Lambda, designed for EMI/EMC suppression in electrical systems. It features a rated voltage of 500 VAC and 500 VDC, with a continuous current rating of 6 A. The unit utilizes a chassis mount installation style and screw termination type for secure connections. With a compact low-profile design, it is suitable for applications requiring secondary side filtering. The component weighs approximately 400 g and complies with UL and EN safety agency standards.

Power Line Filter Modules Feature Summary

• Designed specifically for secondary side three-phase inverters to manage electromagnetic interference
• Features a low-profile physical structure to facilitate integration into space-constrained enclosures
• Complies with UL and EN safety agency standards for industrial reliability

Power Line Filter Modules Applications

• Secondary side filtering for three-phase inverter systems
• Industrial equipment requiring EMI suppression on power lines
• Electrical panels needing compliant power line conditioning

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version and compliance certificates (UL/EN) prior to procurement. Confirm that the 6A current rating and 500V voltage specifications align with the target circuit requirements. Ensure the chassis mount style and screw termination type are compatible with the existing mechanical assembly and wiring infrastructure.

Power Line Filter Modules Selection Notes

Select this component when a single-phase filter with a 6A rating is required for secondary side applications. Consider the chassis mount constraint and ensure adequate clearance for heat dissipation. Verify that the low-profile form factor meets the enclosure height limitations compared to alternative DIN rail or panel mount options.

Power Line Filter Modules Part Context

The RTCN-5006 belongs to the RTCN series of power line filters from TDK-Lambda. This series offers a range of current ratings from 6A to 300A at 500VAC. These filters are engineered for robust performance in industrial environments, providing effective noise attenuation while maintaining safety compliance for critical power distribution networks.

Power Line Filter Modules Replacement Considerations

Consult official substitution guides for equivalent models within the RTCN series or other TDK-Lambda filter families. Verify that any substitute matches the 6A current rating, 500V voltage rating, and chassis mount interface to ensure functional compatibility.
