SL 2 104 8 G

Headers, Male Pins Overview

The SL 2 104 8 G is a male header connector from the Fischer Elektronik SL 2 series, designed for through-hole PCB mounting. It features 8 positions with a 0.100 inch (2.54 mm) pitch and single row configuration. The contacts are gold-plated bronze. The connector supports a temperature range of -40°C to +163°C and withstands soldering at 260°C for 10 seconds. It complies with UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Through-hole mounting for secure PCB integration
• Gold-plated contact surfaces for reliable conductivity
• Single row design with standard 2.54mm spacing

Headers, Male Pins Applications

• General electronic circuit interconnections
• Industrial control panel wiring
• Consumer electronics assembly

Headers, Male Pins Procurement Notes

Verify the exact part number SL 2 104 8 G against manufacturer datasheets to ensure correct pin count and plating specifications. Confirm compatibility with mating sockets regarding height and pitch. Check for RoHS compliance status if required by project regulations. Ensure storage conditions maintain contact integrity prior to assembly.

Headers, Male Pins Selection Notes

Select this component when a single-row, 8-position header with gold contacts is required. Verify that the 2.54mm pitch matches the board layout. Consider the operating temperature range of -40°C to +163°C for environmental suitability. Ensure the through-hole profile fits the PCB thickness and soldering process capabilities.

Headers, Male Pins Part Context

This connector belongs to the SL 2 series of Fischer Elektronik headers. The series offers various pin counts and configurations for board-to-board or cable-to-board connections. The SL 2 104 8 G specifically provides a compact solution for low-density interconnects requiring durable gold contacts.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 8-pin count, 2.54mm pitch, single row, and gold plating. Verify mechanical dimensions including header height and tail length. Cross-reference with other manufacturers' 0.100 inch pitch headers if availability is an issue, ensuring electrical and thermal ratings are equivalent.
