SL LP 2 112 30 S

Headers, Male Pins Overview

The SL LP 2 112 30 S is a male pin header manufactured by Fischer Elektronik, designed for board-to-board and wire-to-board connections. It features a single row with 30 contacts and a standard 2.54 mm pitch. The component utilizes a through-hole straight mounting style for secure PCB integration. Plating options include gold or tin variants within the series, ensuring reliable electrical performance across various industrial applications.

Headers, Male Pins Feature Summary

• Single-row male pin header configuration
• Standard 2.54 mm contact pitch
• Through-hole straight mounting design

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board assemblies
• General electronic circuit prototyping

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm plating type and contact count. Fischer Elektronik uses distinct suffixes to denote variations in surface finish and terminal quantity. Ensure the selected variant matches the required electrical specifications and mechanical constraints of the target assembly before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component based on the requirement for a single-row, high-density connection solution. The 2.54 mm pitch is suitable for standard PCB layouts. Consider the available plating options to match environmental resistance needs. Confirm that the straight through-hole form factor aligns with the mechanical space and orientation requirements of the host device.

Headers, Male Pins Part Context

This part belongs to the Fischer Elektronik SL LP series of male headers. The series offers various contact counts and plating configurations to suit different connectivity needs. The SL LP 2 112 30 S specifically provides a 30-contact option within this standardized connector family, maintaining consistent mechanical dimensions across the range.

Headers, Male Pins Replacement Considerations

Direct substitutes are not explicitly documented in public sources. Verify compatibility with existing mating connectors regarding pitch and row configuration. Alternative single-row headers from other manufacturers may require mechanical re-evaluation of mounting holes and overall height constraints.
