SLG59H1017V

$2.44

Description：IC PWR SWITCH N-CHAN 1:1 18STQFN
Series：-
Mfr：Renesas Electronics Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:46aa0c203166 Category: Power Distribution Switches, Load Drivers Brand: Renesas Electronics Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SLG59H1017V is listed in the Power Distribution Switches, Load Drivers range at ChipApex. The manufacturer field lists Renesas Electronics Corporation. Its product description is IC PWR SWITCH N-CHAN 1:1 18STQFN. Review the specifications below when checking this part for your BOM.

Power Distribution Switches, Load Drivers specifications for SLG59H1017V

Description：IC PWR SWITCH N-CHAN 1:1 18STQFN
Series：-
Mfr：Renesas Electronics Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
Switch Type：General Purpose
Number of Outputs：1
Ratio - Input:Output：1:01
Output Configuration：High Side
Output Type：N-Channel
Interface：On/Off
Voltage - Load：20V
Voltage - Supply (Vcc/Vdd)：Not Required
Current - Output (Max)：4A
Rds On (Typ)：13.1mOhm
Input Type：CMOS
Features：Auto Restart, Load Discharge, Slew Rate Controlled
Fault Protection：Current Limiting (Adjustable), Over Temperature, UVLO
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Supplier Device Package：18-STQFN (1.6x3)
Package / Case：18-PowerUFQFN
Grade：-
Qualification：-

Power Distribution Switches, Load Drivers datasheet and documents for SLG59H1017V

SLG59H1017V

Power Distribution Switches, Load Drivers Overview

The SLG59H1017V is a high-performance NMOS load switch designed for 12V or 24V power rails with up to 4A continuous current. It features a low RDSON of 13.3mΩ and supports an input voltage range of 10.8V to 25.2V. The device includes programmable overvoltage protection, capacitor-adjustable inrush control, and two-stage current limiting (resistor-adjustable active limit and fixed 0.5A short-circuit limit). It operates from -40°C to +85°C in a 1.6mm x 3.0mm STQFN-18 package.

Power Distribution Switches, Load Drivers Feature Summary

Proprietary MOSFET design ensures stable low on-resistance across wide input voltages
Integrated automatic nFET SOA protection and copper pillar interconnects for thermal efficiency
Configurable inrush current control via external capacitor and resistor-adjustable current limits
Active HIGH enable control with fast VOUT discharge capability

Power Distribution Switches, Load Drivers Applications

IO-Link Host and Gateway Systems
Multifunction Printers and Large-format Copiers
Telecommunications Equipment
High-performance Computing Power Distribution
Motor Drives

Power Distribution Switches, Load Drivers Procurement Notes

Verify the specific suffix 'V' indicates RoHS compliance and lead-free status as per Renesas standards. Confirm the STQFN-18 package dimensions match the 1.6mm x 3.0mm specification. Ensure the application circuit correctly implements the required external components for programmable OVP and current limiting functions before finalizing procurement.

Power Distribution Switches, Load Drivers Selection Notes

Select this component when managing 12V or 24V loads requiring precise current monitoring and robust protection. It is suitable for applications needing analog current feedback and configurable soft-start characteristics. Compare against other SLG59 series parts if different channel counts or voltage ranges are required.

Power Distribution Switches, Load Drivers Part Context

Part of the Renesas SLG59 family of integrated power switches. This model specifically targets industrial and telecom power distribution where space constraints and thermal performance are critical. It complements other Renesas PMIC solutions for complete system power management.
