SLV W 1 055 23 Z

Headers, Male Pins Overview

The SLV W 1 055 23 Z is a male pin header manufactured by Fischer Elektronik. It features a through-hole mounting style with a contact pitch of 0.050 inches (1.27mm). The component provides 23 positions for electrical connectivity. It is designed for integration into printed circuit boards to establish reliable connections with mating female headers.

Headers, Male Pins Feature Summary

• Through-hole mounting configuration for secure PCB attachment
• Male pin design compatible with standard female headers
• Standard 1.27mm contact pitch for widespread compatibility

Headers, Male Pins Applications

• General-purpose electronic interconnects
• PCB-to-PCB communication links
• Connector assemblies requiring 23-position alignment

Headers, Male Pins Procurement Notes

Verify the exact pin count and pitch against project requirements before ordering. Confirm that the through-hole footprint matches the target PCB layout. Ensure compatibility with the intended mating female connector series. Check surface finish specifications if environmental resistance is required. Validate mechanical dimensions for enclosure clearance.

Headers, Male Pins Selection Notes

Select this header when a 23-position connection is necessary. The 1.27mm pitch suits dense board layouts. Through-hole technology offers robust mechanical stability compared to surface mount alternatives. Consider the mating interface type to ensure proper engagement. Evaluate space constraints relative to the header profile.

Headers, Male Pins Part Context

This part belongs to Fischer Elektronik's SLV W series of male headers. These components are engineered for use with corresponding female headers, such as the BLV series. The series focuses on providing standardized interconnect solutions for various electronic applications requiring reliable signal or power transmission.
