SMHV0560N-S2

SMHV0560N-S2 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists HVM Technology, Inc.. Its product description is DC DC CONVERTER -6000V 1W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for SMHV0560N-S2

• Description：DC DC CONVERTER -6000V 1W
• Series：SMHV
• Mfr：HVM Technology, Inc.
• Package：Box
• Type：Non-Isolated PoL Module
• Number of Outputs：1
• Voltage - Input (Min)：4.5V
• Voltage - Input (Max)：5.5V
• Voltage - Output 1：-6000V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：167µA
• Power (Watts)：1 W
• Voltage - Isolation：-
• Applications：ITE (Commercial)
• Features：Adjustable Output
• Operating Temperature：-55°C ~ 70°C
• Efficiency：60%
• Mounting Type：Through Hole
• Package / Case：9-DIP Module
• Size / Dimension：0.85" L x 0.85" W x 0.60" H (21.6mm x 21.6mm x 15.2mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for SMHV0560N-S2
