SML-LXLC1206SIC-TR

LED Indication - Discrete Overview

The SML-LXLC1206SIC-TR is a single-color surface-mount LED manufactured by Lumex Opto/Components Inc. It features a red lens with a rectangular shape and water-clear transparency, housed in a 1206 (3216 metric) package measuring 3.2 mm in length, 1.5 mm in width, and 1.05 mm in height. The component emits light at a peak wavelength of 636 nm with a luminous intensity of 70 mcd. It operates with a forward current of 20 mA and a forward voltage of 2 V, rated for a power dissipation of 100 mW. The device supports a temperature range from -30 °C to 85 °C.

LED Indication - Discrete Feature Summary

• Surface-mount construction in a standard 1206 footprint for automated assembly
• Water-clear rectangular lens designed for focused light emission
• Compliant with RoHS standards for environmental safety

LED Indication - Discrete Applications

• General indicator lighting on electronic circuit boards
• Status indication in consumer electronics devices
• Panel mounting for visual signal display

LED Indication - Discrete Procurement Notes

Verify the exact suffix configuration against the manufacturer's official datasheet to ensure correct optical and electrical specifications. Confirm that the ordering part number matches the required lens type and wavelength parameters before finalizing procurement orders to avoid component mismatch.

LED Indication - Discrete Selection Notes

Select this component when a standard red indicator is required in a compact 1206 form factor. Ensure the design accommodates the specified 2 V forward voltage drop and 20 mA drive current. Verify thermal management capabilities within the -30 °C to 85 °C operating range for the intended application environment.

LED Indication - Discrete Part Context

This component belongs to Lumex's line of standard surface-mount LEDs. It shares the physical 1206 dimensions with other variants in the series but differs in optical properties such as color and intensity. The 'SIC' designation typically denotes specific lens and die characteristics within the manufacturer's catalog structure.

LED Indication - Discrete Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Cross-referencing with similar 1206 red LEDs requires careful verification of forward voltage, peak wavelength, and mechanical height constraints.
