SN74AVCH24T245ZRGR

Buffers, Drivers, Receivers, Transceivers Overview

The SN74AVCH24T245ZRGR is a 24-bit dual-supply bus transceiver manufactured by Texas Instruments. It operates within a voltage range of 1.2 V to 3.6 V and supports data rates up to 380 Mb/s. The device features a propagation delay of 5 ns and functions across an operating temperature range from -40°C to +85°C. Packaged in an NFBGA-83 format, it provides 3-state outputs for effective bus management.

Buffers, Drivers, Receivers, Transceivers Feature Summary

• Supports configurable voltage-level shifting between independent power rails
• Enables asynchronous communication across two data buses
• Includes partial power-down capability via IOFF circuitry

Buffers, Drivers, Receivers, Transceivers Applications

• Personal electronic devices
• Industrial automation systems
• Enterprise telecommunications infrastructure

Buffers, Drivers, Receivers, Transceivers Procurement Notes

Verify the specific suffix against official documentation to confirm package type and tape-and-reel specifications. Confirm RoHS compliance status directly with the manufacturer or authorized distributors, as regulatory markings may vary by production batch. Ensure the component meets all environmental operating requirements for your specific deployment scenario.

Buffers, Drivers, Receivers, Transceivers Selection Notes

Select this component when interfacing high-density buses requiring 24 channels of bidirectional translation. It is suitable for applications needing low-power operation with configurable voltage domains. Consider the NFBGA-83 package constraints for PCB layout and thermal management during the design phase.

Buffers, Drivers, Receivers, Transceivers Part Context

This part belongs to the SN74AVCH24T245 series of logic ICs. It serves as a voltage level translator within the AVC family, designed for robust signal integrity in mixed-voltage environments. The device integrates standard CMOS inputs with push-pull outputs for reliable data transmission.

Buffers, Drivers, Receivers, Transceivers Replacement Considerations

Consult official substitution guides for compatible alternatives. Verify pinout compatibility and electrical parameters before replacing.
