SX5A25.000F0810F30G

Crystals Overview

The SX5A25.000F0810F30G is a surface mount passive crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates at a fundamental frequency of 25 MHz and utilizes an AT-cut crystal structure housed in a glass-sealed ceramic package. The component features a load capacitance of 8 pF and an equivalent series resistance (ESR) of 30 Ohms. Frequency stability is rated at ±10 ppm over room temperature conditions, with a broader tolerance of ±30 ppm across the operating range. The device is designed for high reliability and precision timing applications.

Crystals Feature Summary

• AT-cut crystal structure for enhanced thermal stability
• Glass-sealed ceramic surface mount packaging
• High precision frequency control capabilities

Crystals Applications

• General purpose digital clock signal generation
• Microcontroller system timing references
• Communication interface synchronization

Crystals Procurement Notes

Verify that the specific ordering suffix matches the required load capacitance and frequency tolerance specifications. Confirm the package type aligns with the PCB footprint requirements. Ensure compliance with RoHS standards if environmental regulations apply to the final assembly. Cross-reference the manufacturer's latest datasheet to confirm current production status and availability before placing orders.

Crystals Selection Notes

Select this component when a 25 MHz reference is required with ±10 ppm room temperature stability. The 8 pF load capacitance must match the circuit design parameters. Consider the SMD5032-2P package dimensions for board space constraints. Evaluate the ESR value against the oscillator circuit drive level requirements to ensure stable operation without overdriving the crystal.

Crystals Part Context

This part belongs to the SX5A series of surface mount crystals from Shenzhen SCTF Electronics. The series focuses on providing reliable timing solutions using AT-cut technology. The model number encodes key electrical parameters including frequency, load capacitance, and tolerance levels. It represents a standard offering for general electronic applications requiring precise frequency generation.

Crystals Replacement Considerations

Direct substitutes must maintain the 25 MHz frequency, 8 pF load capacitance, and compatible package dimensions. Verify that alternative components meet the same ±10 ppm stability requirement. Check for identical mounting footprints to ensure mechanical compatibility without redesigning the PCB layout.
