THS6022CGQER

Drivers, Receivers, Transceivers Overview

The THS6022CGQER is a dual differential line driver manufactured by Texas Instruments. It features a 14-pin HTSSOP package and operates within a temperature range of -40°C to 85°C. The device provides a 250-mA output current capability and supports single-supply operation from 9V to 32V. It is designed for high-speed applications including asymmetrical digital subscriber line (ADSL) at the remote terminal and high-data-rate digital subscriber line (HDSL).

Drivers, Receivers, Transceivers Feature Summary

• Dual differential line driver architecture for balanced signal transmission.
• High output current drive capability of 250 mA per channel.
• Operates on a wide single supply voltage range from 9V to 32V.
• Suitable for high-speed data communication interfaces.

Drivers, Receivers, Transceivers Applications

• Asymmetrical digital subscriber line (ADSL) remote terminals
• High-data-rate digital subscriber line (HDSL) systems
• Very-high-bit-rate digital subscriber line (VHDSL) applications

Drivers, Receivers, Transceivers Procurement Notes

Verify the specific suffix CGQER against the official Texas Instruments datasheet to confirm package type, pinout, and electrical characteristics match your design requirements. Ensure the component meets RoHS compliance standards if required by your manufacturing process. Cross-reference the manufacturer part number with authorized distributors to confirm availability and authenticity before procurement.

Drivers, Receivers, Transceivers Selection Notes

Select this component when a dual differential line driver with high current drive is needed for long-distance copper-based telecommunications. Consider the 9V to 32V single-supply requirement and the HTSSOP package constraints. Evaluate thermal performance given the 250-mA output capability in your PCB layout design.

Drivers, Receivers, Transceivers Part Context

The THS6022 belongs to Texas Instruments' family of high-speed operational amplifiers and line drivers. It is specifically engineered for telecommunication infrastructure requiring robust signal integrity over twisted-pair cables. The device complements other THS series components used in modem and network interface equipment.

Drivers, Receivers, Transceivers Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult the official Texas Instruments product selection guide or contact technical support for verified alternatives that meet identical electrical and mechanical specifications.

Drivers, Receivers, Transceivers FAQ

What is the operating supply voltage range for the THS6022CGQER?

The device operates on a single supply voltage ranging from 9V to 32V.

What is the maximum output current per channel?

Each channel of the dual differential line driver can provide up to 250 mA of output current.
