TMM-104-01-L-S-RA

$0.77

Description：CONN HEADER R/A 4POS 2MM
Series：TMM
Mfr：Samtec Inc.
Package：Bulk

SKU:36636856b958 Category: Headers, Male Pins Brand: Samtec Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

TMM-104-01-L-S-RA is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Samtec Inc.. Its product description is CONN HEADER R/A 4POS 2MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for TMM-104-01-L-S-RA

Description：CONN HEADER R/A 4POS 2MM
Series：TMM
Mfr：Samtec Inc.
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：4
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.126" (3.20mm)
Contact Length - Post：0.120" (3.05mm)
Overall Contact Length：-
Insulation Height：0.079" (2.00mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：10.0µin (0.25µm)
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Liquid Crystal Polymer (LCP)
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：Black
Current Rating (Amps)：3.2A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for TMM-104-01-L-S-RA

TMM-104-01-L-S-RA

Headers, Male Pins Overview

The TMM-104-01-L-S-RA is a low-profile Tiger Eye header strip from the Samtec TMM series. It features a single row with four male pin contacts and a 2.00 mm (0.079 inch) pitch. Designed for right-angle surface mount installation, it utilizes solder terminals for board attachment. The connector employs phosphor bronze contacts with selective gold plating on the mating area and matte tin on the tail. The insulator is constructed from black liquid crystal polymer (LCP), rated UL 94 V-0, supporting an operating temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

Low profile design optimized for space-constrained applications
Right-angle orientation facilitates compact board-to-board interconnects
Selective gold plating ensures reliable signal transmission

Headers, Male Pins Applications

Board-to-board interconnections
Cable-to-board connections
High-density electronic assemblies

Headers, Male Pins Procurement Notes

Verify that the specific suffix 'L' indicates selective gold plating rather than standard tin or full gold options. Confirm the right-angle mounting style matches the PCB footprint requirements. Ensure the component complies with RoHS3 standards as specified in the manufacturer documentation. Cross-reference the lead length specifications against assembly constraints.

Headers, Male Pins Selection Notes

Select this variant when right-angle mounting is required for a four-position connection. The low-profile form factor suits applications with strict height limitations. Verify that the 2.00 mm pitch aligns with the mating connector interface. Consider the thermal performance of LCP insulation for high-temperature environments.

Headers, Male Pins Part Context

This component belongs to the TMM series of terminal strips by Samtec Inc. The series offers various configurations including shrouded and unshrouded options with different plating and mounting styles. The TMM-104-01-L-S-RA specifically addresses needs for angled, low-height connections in modern electronics manufacturing.
