TSW-112-20-L-D-LL

Headers, Male Pins Overview

Samtec TSW-112-20-L-D-LL is a classic PCB header strip featuring a 0.100 inch (2.54 mm) pitch and double row configuration with 20 positions per row. It utilizes phosphor bronze contacts with gold plating for reliable signal transmission. The connector supports through-hole termination and operates within a temperature range of -55°C to +125°C. Constructed with black polybutylene terephthalate insulation rated UL94 V-0, it provides robust mechanical stability. This component is designed for board-to-board or cable applications, offering high retention and cost-effective performance for standard interconnect needs.

Headers, Male Pins Feature Summary

• Features industry-standard 0.100 inch pitch for versatile compatibility
• Utilizes gold-plated phosphor bronze contacts for enhanced conductivity
• Supports vertical orientation with through-hole solder termination
• Constructed with UL94 V-0 rated PBT insulation for thermal stability

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• General purpose electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to ensure correct pin count, row configuration, and plating thickness. Confirm that the lead style matches the target PCB footprint requirements. Check RoHS compliance status and moisture sensitivity level before integration into production workflows to avoid assembly defects.

Headers, Male Pins Selection Notes

Select this model when a double-row, through-hole header with 0.100 inch spacing is required. Ensure the mating socket has compatible contact retention and alignment features. Consider the operating temperature range and current rating relative to the application load. Verify that the insulation material meets the environmental and flammability standards of the end product.

Headers, Male Pins Part Context

The TSW series represents Samtec's classic line of PCB header strips, known for design flexibility and extensive availability. This specific part belongs to the standard .100 inch pitch family, widely used in general electronics. It complements related components like Tiger Buy socket strips and offers various terminal length options for optimized performance.

Headers, Male Pins Replacement Considerations

Direct substitutes may include other Samtec TSW variants with matching pitch and row count. Verify cross-compatibility with mating sockets from different manufacturers by checking contact dimensions and retention forces. Ensure electrical ratings and physical dimensions align perfectly before substitution.
