V1081NG--20C000242U1930

$0.21

Description：LED GREEN CLEAR 2SMD R/A
Series：V1081NG--20
Mfr：Harvatek Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:05353f9e9340 Category: LED Indication - Discrete Brand: Harvatek Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

V1081NG–20C000242U1930 is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Harvatek Corporation. Its product description is LED GREEN CLEAR 2SMD R/A. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for V1081NG–20C000242U1930

Description：LED GREEN CLEAR 2SMD R/A
Series：V1081NG--20
Mfr：Harvatek Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Green
Configuration：-
Lens Color：-
Lens Transparency：Clear
Millicandela Rating：1125mcd
Lens Style：Irregular
Lens Size：-
Voltage - Forward (Vf) (Typ)：3V
Current - Test：20mA
Viewing Angle：120°
Mounting Type：Surface Mount, Right Angle
Wavelength - Dominant：525nm
Wavelength - Peak：520nm
Features：-
Package / Case：2-SMD, No Lead
Supplier Device Package：2-SMD
Size / Dimension：2.80mm L x 14.00mm W
Height (Max)：0.90mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for V1081NG–20C000242U1930

V1081NG--20C000242U1930

LED Indication - Discrete Overview

The V1081NG--20C000242U1930 is a surface-mount LED indicator manufactured by Harvatek Corporation. It features a green color with a peak wavelength of 520nm and a dominant wavelength of 525nm. The component utilizes a 2-SMD, no-lead package with dimensions of 2.8mm length, 1.2mm width, and 0.8mm maximum height. It operates at a forward voltage of approximately 3V and has a test current of 20mA. The device is RoHS compliant and classified under ECCN EAR99.

LED Indication - Discrete Feature Summary

Green light emission with specified peak and dominant wavelengths
Surface mount technology with no-lead 2-SMD configuration
Compact physical dimensions suitable for space-constrained designs

LED Indication - Discrete Applications

Electronic status indication
Panel mounting indicators
Consumer electronics signaling

LED Indication - Discrete Procurement Notes

Verify the specific ordering suffix to ensure compatibility with required packaging options such as tape and reel or cut tape. Confirm that the lead-free construction meets environmental regulations for the target market. Check moisture sensitivity level handling requirements during storage and assembly processes to prevent damage before soldering.

LED Indication - Discrete Selection Notes

Select this component when a green surface-mount indicator is required for discrete applications. Ensure the PCB footprint matches the 2.8mm by 1.2mm outline. Consider the forward voltage drop in circuit design to properly size current-limiting resistors. Verify that the viewing angle specifications meet visibility requirements for the intended enclosure.

LED Indication - Discrete Part Context

This part belongs to the V1081 series of surface-mount LEDs from Harvatek Corporation. The series offers various colors and configurations in compact packages. The V1081NG variant specifically denotes the green color option within this family, designed for general-purpose indication tasks in modern electronic assemblies.
