XC5VTX240T-1FFG1759C

Field Programmable Gate Array Overview

The XC5VTX240T-1FFG1759C is a high-performance Field Programmable Gate Array (FPGA) from the AMD Xilinx Virtex-5 TX family. It features 239,616 logic elements and 37,440 Adaptive Logic Modules (ALMs). The device includes 11.39 Mbit of embedded memory, comprising 2,400 kbit distributed RAM and 11,664 kbit embedded block RAM. It supports up to 680 I/Os and operates with a minimum supply voltage of 1 V. The maximum operating frequency is 550 MHz, with a data rate of 6.5 Gb/s for its transceivers. It contains 48 transceivers and is housed in a 1759-ball FCBGA package.

Field Programmable Gate Array Feature Summary

• High-density programmable logic architecture with extensive embedded memory resources
• Integrated high-speed serial transceivers supporting multi-gigabit data rates
• Support for complex digital signal processing and system-level integration

Field Programmable Gate Array Applications

• High-speed networking equipment
• Data center infrastructure acceleration
• Test and measurement instrumentation

Field Programmable Gate Array Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm the specific suffix 'C' indicates commercial temperature range operation. Check for end-of-life status as some Virtex-5 variants have reached obsolescence. Ensure compatibility with existing PCB footprints and thermal management solutions before procurement.

Field Programmable Gate Array Selection Notes

Select this model when high logic density and significant embedded memory are required within a single FPGA. Compare against lower-density Virtex-5 variants if resource utilization is low. Consider the FF1759 package size for board space constraints. Verify that the 1 speed grade meets timing requirements for target clock frequencies.

Field Programmable Gate Array Part Context

This component belongs to the Virtex-5 TX series, optimized for high-speed serial communications. It shares the same package footprint with other devices in the 1759 FCBGA form factor. The TX designation highlights its focus on transceiver capabilities compared to standard LX or ML series devices.

Field Programmable Gate Array Replacement Considerations

Direct pin-to-pin replacements may include other Virtex-5 TX devices in the FF1759 package, such as the XC5VTX330T or XC5VTX50T, provided logic resources are sufficient. Upgrades to Virtex-6 or UltraScale+ families require redesign due to architectural differences.
