XH30M00000S416

Crystals Overview

The XH30M00000S416 is a 30 MHz crystal oscillator manufactured by TGS. It features an HC-49SX package and operates with a load capacitance of 16 pF. The component exhibits a frequency stability of ±30 ppm and an equivalent series resistance (ESR) rated at 30 Ohms. These specifications define its electrical performance characteristics for timing applications.

Crystals Feature Summary

• Provides stable oscillation at a nominal frequency of 30 MHz
• Utilizes the HC-49SX package format for mounting
• Maintains frequency stability within ±30 ppm tolerance

Crystals Applications

• General purpose timing circuits
• Microcontroller clock sources
• Communication equipment oscillators

Crystals Procurement Notes

Verify the exact part number against official manufacturer documentation to ensure compatibility with specific circuit requirements. Confirm that the HC-49SX package dimensions and pinout match the design layout. Check datasheet specifications for load capacitance and ESR values to validate performance in the target application environment.

Crystals Selection Notes

Select this component when a 30 MHz reference signal is required with moderate stability. The HC-49SX package offers standard mounting options. Ensure the system design accommodates the 16 pF load capacitance and 30 Ohm ESR parameters specified in the official documentation for proper oscillator circuit operation.

Crystals Part Context

This part belongs to the TGS crystal oscillator product line, specifically utilizing the HC-49SX form factor. It serves as a passive resonant element for generating precise clock signals in electronic systems requiring fixed frequency operation.

Crystals Replacement Considerations

Consult official substitution lists from TGS or authorized distributors for verified equivalents. Cross-reference package type, frequency, and electrical parameters before replacing.
