1.5KE82C-B

1.5KE82C-B is listed in the Tvs Diodes range at ChipApex. The manufacturer field lists Littelfuse Inc.. Its product description is TVS DIODE 70.1VWM 118.65V DO201. Review the specifications below when checking this part for your BOM.

Tvs Diodes specifications for 1.5KE82C-B

• Description：TVS DIODE 70.1VWM 118.65V DO201
• Series：1.5KE
• Mfr：Littelfuse Inc.
• Package：Bulk
• Type：Zener
• Bidirectional Channels：1
• Voltage - Reverse Standoff (Typ)：70.1V
• Voltage - Breakdown (Min)：73.8V
• Voltage - Clamping (Max) @ Ipp：118.65V
• Current - Peak Pulse (10/1000µs)：13.5A
• Power - Peak Pulse：1500W (1.5kW)
• Power Line Protection：No
• Applications：General Purpose
• Capacitance @ Frequency：-
• Operating Temperature：-55°C ~ 175°C (TJ)
• Mounting Type：Through Hole
• Package / Case：DO-201AA, DO-27, Axial
• Supplier Device Package：DO-201
• Unidirectional Channels：-
• Grade：-
• Qualification：-

Tvs Diodes datasheet and documents for 1.5KE82C-B
