1-770874-1

Headers, Male Pins Overview

The 1-770874-1 is a pin header connector from the Mini-Universal MATE-N-LOK series by TE Connectivity AMP Connectors. It features a through-hole vertical mounting style with a 4.14 mm (0.163 inch) pitch. The housing accommodates 4 contacts arranged in a dual-row configuration. Contacts are gold-plated for reliable signal transmission. Designed for wire-to-board applications, this component ensures secure electrical connections in various electronic assemblies.

Headers, Male Pins Feature Summary

• Dual-row contact arrangement for compact board space utilization
• Gold-plated contacts to ensure stable signal integrity
• Through-hole vertical mounting for robust PCB attachment

Headers, Male Pins Applications

• Wire-to-board interconnections
• General electronic equipment assembly
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify the specific packaging quantity and reel specifications when ordering, as availability may vary between cut strips and full reels. Confirm that the gold plating specification matches your design requirements for signal integrity. Ensure compatibility with the corresponding socket connectors within the Mini-Universal MATE-N-LOK family for proper mating.

Headers, Male Pins Selection Notes

Select this part for applications requiring a 4-position dual-row header with a 4.14 mm pitch. The gold plating makes it suitable for sensitive signal lines where corrosion resistance is critical. Consider the through-hole mounting method for mechanical stability compared to surface mount alternatives.

Headers, Male Pins Part Context

This component belongs to the Mini-Universal MATE-N-LOK series, a widely used line of rectangular connectors known for their reliability and versatility. The series supports various contact counts and configurations, making it a standard choice for general-purpose interconnect needs across multiple industries.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 4-position dual-row headers from the same Mini-Universal MATE-N-LOK series with matching 4.14 mm pitch and through-hole termination. Verify that any alternative maintains the gold contact plating and identical housing dimensions for direct interchangeability.
