1-794040-0

Headers, Male Pins Overview

The TE Connectivity AMP Connectors part number 1-794040-0 is a Pin & Socket Connector belonging to the Mini-Universal MATE-N-LOK series. It is a Header connector designed for vertical PCB mounting with a through-hole termination method. The component features 12 positions arranged in a single row, utilizing tin-plated contacts. The housing is constructed from nylon material, and the connector operates at a rated voltage of 600 V and a current capacity of 9.5 A.

Headers, Male Pins Feature Summary

• Vertical pin header configuration for direct printed circuit board integration
• Mini-Universal MATE-N-LOK series design for reliable signal transmission
• Through-hole termination ensures secure mechanical attachment

Headers, Male Pins Applications

• Industrial control systems requiring robust power or signal interconnects
• General-purpose electronic equipment utilizing standard PCB headers
• Automotive electronics applications compatible with MATE-N-LOK specifications

Headers, Male Pins Procurement Notes

Verify that the specific order matches the 1-794040-0 designation, as similar MATE-N-LOK variants exist with different position counts or plating options. Confirm compatibility with mating sockets within the same series. Ensure the vertical orientation and through-hole pitch align with the target PCB layout requirements before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a 12-position vertical header is required for 600V applications. The Mini-Universal MATE-N-LOK series offers a balance of density and reliability. Consider the 9.5A current rating against system load requirements. Verify that the tin contact plating meets environmental corrosion resistance needs for the intended operating conditions.

Headers, Male Pins Part Context

This connector belongs to the extensive MATE-N-LOK family produced by TE Connectivity AMP Connectors. The Mini-Universal variant is widely used in industrial and automotive sectors. It represents a standardized solution for high-current and signal distribution on printed circuit boards, known for its consistent performance across various harsh environments.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 12-position vertical headers within the Mini-Universal MATE-N-LOK series, such as 1-794040-1 if gold plating is preferred. Ensure any replacement maintains the 4.14mm pitch and 600V rating.
